Dock Leveler
Dock Leveler: Automatic Dock Solutions
Dock leveler, which is a device for adjusting the height difference between the truck and the loading platform. It can effectively adjust the height difference between the floor and platform of different transportation vehicles through hydraulic, mechanical or pneumatic system, so as to facilitate the forklift and other handling equipment to enter and exit the trucks for material handling.
Choosing SEPPES Loading Dock Equipment means investing in a solution that combines reliability, efficiency, and safety—essential for any business looking to optimize its logistics workflow.


Structure Design of Loading Dock Leveler
Understand how loading dock levelers can improve efficiency and safety in the loading process.

- 1.Tail lip
- 2.Side curtain safety baffle
- 3.Lip plate cylinder
- 4.Platform support steel
- 5.Lifting cylinder
- 6.Hydraulic pump
- 7.Sealing rubber strip
- 8.Yellow and black warning strips
- 9.Pedestal
- 10.Control unit
Technical Specifications of SEPPES Dock Leveler
Size(mm): | W2000mm*L2000mm*H600mm (Customized) | |||||||||||||||||||||
Table Thickness(mm) | 8mm thickness patterned steel plate of high quality Bengang | |||||||||||||||||||||
Color : | Black/Blue /Grey(OPTION) | |||||||||||||||||||||
Length of Tongue Plate(mm) | 400(500mm is optional) | |||||||||||||||||||||
Height of Equipment (mm) | 600 | |||||||||||||||||||||
Scope of Adjustment (mm) | 300,-300 | |||||||||||||||||||||
Ambient Temperaturer(Celsius) | 0-30℃–80℃ | |||||||||||||||||||||
Load Description | Dynamic load 6T/8T/10T | |||||||||||||||||||||
Power Group | Single-phase asynchronous motor 110V,50HZ,1.1KW,1400r/min | |||||||||||||||||||||
Oil Cylinder | Top lift cylinder Φ80*2 inner diameter, tongue plat cylinder φ50*1 | |||||||||||||||||||||
Main Girder | Bensteel high strength rectangular tube 120*60*4mm, | |||||||||||||||||||||
ControlBbox | 24V electrovalve ,3/8 threads | |||||||||||||||||||||
Protection level: | IP54 | |||||||||||||||||||||
Anti-collision Block | 300mm*200mm*100mm rubber pads(OPTION) |
More Details of Warehouse Dock Leveler
Details determine the quality of dock leveler. High-quality materials will make dock levelers stand out and become the preferred product for enterprises and factories.

Advanced Control System

High Quality PVC Curtain

Double-layer brush sealing structure

Infrared safety photoelectric
We Provide All Types Of Warehouse Dock Levelers
Loading Dock Levelers are indispensable equipment in modern logistics and warehousing.

Hydraulic Dock Leveler
Hydraulic dock leveler is a commonly used loading equipment in industrial settings. It is primarily designed to bridge the height gap between a truck’s trailer and the loading platform, ensuring the safe and efficient transfer of goods. Hydraulic dock levelers are widely utilized in logistics warehouses, manufacturing plants, cold chain warehouses, and other facilities. By using a hydraulic system, they provide smooth and precise lifting operations, significantly improving loading efficiency and operational safety.
Vertical Dock Leveler
Vertical dock leveler is a specialized type of loading dock equipment designed to bridge the gap between a loading dock and a truck trailer, with the unique feature of being stored in an upright, vertical position when not in use. This allows for enhanced cleanliness, temperature control, and security in facilities such as cold storage, food processing plants, and pharmaceutical warehouses, where hygiene and environmental control are crucial.


Edge Of Dock Leveler
Edge of dock leveler is a cost-effective loading dock solution designed to bridge the gap between the dock and truck trailer. Unlike other loading dock levelers, the edge of dock leveler is mounted directly on the edge of the loading dock, making it ideal for facilities with minimal height differences between the dock and trailer. It allows for quick and efficient loading and unloading operations without the need for a full-sized pit leveler.
We Have Authentic And Authoritative Certificates
With Over 20 Patents and Certifications, We Guarantee the Highest Industry Standards for Our Dock Levelers





Get an Instant Quote for Your Factory!
SEPPES is committed to providing types of loading dock leveler for your business.
Supporting Subheading
Professional Dock Leveler Factory Manufacturing









High Speed Zipper Door

High Speed Stacking Door

High Speed Freezer Door

High Speed Spiral Door

Aluminum Roller Shutter

Sectional Door

Dock Leveler

Dock Shelter
Why Choose Seppes Loading Dock Leveler
Superior design, premium quality and a growing list of satisfied customers have made Seppes a pioneer in the industrial door industry. All main fast door products with CE and ISO9001 certificate.
13 Years Manufacturing Experience
We have 13 years of production experience and a large factory of 17,500 square meters. We guarantee the quality of our products through professional production equipment.
Big Brand Trust
As a global company, Seppes currently supplies industrial doors and loading docks to more than 3,800 companies, including Fuji, Johnson & Johnson Medical, Thermo Fisher, and so on.
24/7 Online Support
The business staff will provide you with 7*24 hours online: question answering, product quotation, payment and delivery, installation and after-sales…
Comprehensive Solutions
From consultation to implementation, we offer end-to-end solutions tailored to your needs, ensuring a seamless experience.
Timely Delivery
We value your time and strive to deliver our services promptly and efficiently, meeting deadlines without compromising on quality.
Professional Technician
We leverage the latest technologies and techniques to deliver cutting-edge solutions that meet the demands of today’s dynamic market.
Frequently Asked Questions About Dock Leveler
We have compiled the most frequently asked questions about hydraulic dock leveler here for your convenience. But if you can’t find what you’re looking for in our FAQs, please Give us a call at +8617768032191 or get in touch at diana@seppes.com.cn.
